^BE · EAN‑13 barcode
Generates an EAN‑13 barcode.
Syntax and practical example
^BEo,h,f,gExample: ^BEN,80,Y,N
^XA
^PW600
^LL400
^FO40,60^BY3
^BEN,100,Y,N^FD590123412345^FS
^XZEducational example; not a certified label or a physical print test. Sample text and codes stay the same in every language for comparison.
Expected result with ^BE
^FD contains the 12 digits 590123412345. The printer adds check digit 7, giving expected value 5901234123457. Module width is 3 dots and bars are 100 dots high; preserve white space on both sides.
What should I check if ^BE does not give the expected result?
Do not paste a complete 13-digit GTIN without adapting the data passed to ^BE. Validate the 12 input digits: automatic padding or truncation can produce a different number. This example does not allocate a commercial GTIN to your product.
